HPE 5140 Switches Datasheet

HPE FlexNetwork 5140 EI & HI Switch Series - Technical Datasheet Index

HPE FlexNetwork 5140 Switch Series - Technical Datasheet Index

Source Reference: Optdex HPE 5140 Series Collection. Hardware specifications index covering HPE FlexNetwork 5140 EI (Enhanced Image) and 5140 HI (High Image) Gigabit Ethernet Layer 3 access switches featuring 10GbE SFP+ uplinks, Smart Rate Multi-Gigabit support, Intelligent Resilient Fabric (IRF) stacking, PoE+ (370W/740W budgets), and Comware v7 operating system architecture.

1. HPE FlexNetwork 5140 EI Series (Gigabit Access & 10G Uplinks)

Model Name	HPE Part Number	Access Ports Configuration	Uplink Interfaces	PoE / Power Budget	Routing & Stacking Profile
HPE 5140 24G 4SFP+ EI	R8N85A / JL829A	24x 10/100/1000BASE-T RJ45	4x 10G/1G SFP+ Ports	Non-PoE (Internal AC Power)	Layer 3 Static / OSPFv1/v2, IRF Stacking
HPE 5140 48G 4SFP+ EI	R8N88A / JL828A	48x 10/100/1000BASE-T RJ45	4x 10G/1G SFP+ Ports	Non-PoE (Internal AC Power)	Layer 3 Static / OSPFv1/v2, IRF Stacking
HPE 5140 24G PoE+ 4SFP+ EI	R8N86A / JL827A	24x 10/100/1000BASE-T RJ45 PoE+	4x 10G/1G SFP+ Ports	IEEE 802.3at PoE+ (370W Budget)	Layer 3 RIP/OSPF, IRF Stacking
HPE 5140 48G PoE+ 4SFP+ EI	R8N87A / JL826A	48x 10/100/1000BASE-T RJ45 PoE+	4x 10G/1G SFP+ Ports	IEEE 802.3at PoE+ (370W / 740W w/ RPS)	Layer 3 RIP/OSPF, IRF Stacking

2. HPE FlexNetwork 5140 HI Series (High Image & Smart Rate Multi-Gigabit)

Model Name	HPE Part Number	Access Ports Configuration	Uplink & Expansion Options	Power & High-Availability Profile
HPE 5140 24G 4SFP+ HI	ROP01A / R0P01A	24x 10/100/1000BASE-T RJ45	4x 10G SFP+ + 1x Expansion Slot	Dual Modular Hot-Swap Power Supplies
HPE 5140 48G 4SFP+ HI	ROP02A / R0P02A	48x 10/100/1000BASE-T RJ45	4x 10G SFP+ + 1x Expansion Slot	Dual Modular Hot-Swap Power Supplies
HPE 5140 8MG 16G PoE+ HI	R8N89A / R0P04A	8x 100/1000/2.5G Smart Rate + 16x 1GbE PoE+	4x 10G SFP+ Ports	IEEE 802.3at PoE+ High-Density Budget

3. Power Modules, Direct Attach Cables & Optical Transceivers

Part Number	Category	Description	Compatibility Profile
JD092B	SFP+ Transceiver	HPE X130 10G SFP+ LC SR Transceiver (Multi-mode Fiber)	HPE 5140 EI / HI 10GbE Uplink & IRF Stacking Ports
JD094B	SFP+ Transceiver	HPE X130 10G SFP+ LC LR Transceiver (Single-mode Fiber)	HPE 5140 EI / HI 10GbE Uplink Ports
JD096C	DAC Cable	HPE FlexNetwork X240 10G SFP+ to SFP+ 1.2m Direct Attach Copper Cable	High-Speed IRF Stacking between 5140 Switches
R0P00A / R0P03A	Modular Power Supply	HPE 150W / 500W AC Power Supply Module	HPE 5140 HI Series Dual Redundant Power Bays
